Food Printer
Food Printer MMP-F13BC
Product Description
A conveyor model based on the food printer "MMP-F13" has debuted.
Operability, functionality and maintainability are the same as for the MMP-F13, but with improved production specifications.
Printing is possible with simple operation.
Anyone can operate it easily.
● Operability... Easy-to-read and easy-to-use touch panel.
● Functionality... Sensors detect the material to prevent contact between the material and the print head.
●Maintenance: The front cover opens wide for easy access, making printer maintenance simple!
Product Specifications
| Printing Method | Piezoelectric Inkjet |
|---|---|
| Print Resolution | 360～2880dpi・4 Steps |
| Printing Material Thickness | Max. 100 mm |
| Print width and conveyor length | Max. 315㎜ width, 2,100㎜ length |
| Printable material dimensions | Within 315 mm (width) x 483 mm (length) x 100 mm (height) |
| Printing Drive Mechanism | Belt Moving Mechanism |
| Height Adjustment Mechanism | Manual lifting mechanism with handle |
| Control Panel | Touch Panel Method |
| Print Speed (max. size, 7-colour mode) | Approx. 2 min 20 sec 720 dpi/unidirectional |
| Print Speed (max. size, 4-colour mode) | Approx. 1 min 10 sec 720 dpi/unidirectional |
| Interfaces | USB 2.0 |
| Rated voltage/current | ＡＣ１００Ｖ～２４０V±１０％ |
| Ink Composition | 7-color mode (Cyan, Red, Yellow, Black, Light Cyan, Light Red, Light Black)
4-color mode (Cyan, Red, Yellow, Black) |
| Ink Supply Method | Individual bottles for each color (125ml capacity) |
| Ink Type | Synthetic dye edible ink (7 colors / 4 colors), natural dye edible ink (4 colors) |
| Weight | Approx. 100 kg approx. 80 kg (base and conveyor section) + approx. 20 kg (printer section) |
| Dimensions (Base part) | 710 mm (width) x 2,120 mm (depth) x 1,200 mm (height) (including patrol lights) |
| Recommended OS | Windows 10 or later |
